详细信息
CPU：板载Intel Core i5-3210M i7-3520M GPU
芯片组：Intel HM76
内存：DDR3 SO-DIMM
I/O端口：1*LINE OUT&MIC,6*USB,2*LAN,1*HDMI,1*VGA,1*KB/MS
串口：2*RS-232,2*RS-232/422/485
看门狗:256级,可编程时间到中断、时间到系统复位
存储：1*2.5"SATA盘位
扩展槽位：1个PCI(或PCIE X1)槽位
扩展总线:1个标准mPCIEx1接口或mSATA
电源:DC_IN 12~24V
尺寸:246*209*114mm(W*D*H)
| System Hardware | Processor | Intel® Core™ i5-3320M Processor (3M Cache, up to 3.30 Ghz) |
| BIOS | 32Mb AMI SPI | |
| Chipset | Intel HM76 | |
| Memory | 2*204 Pin SO-DIMM socket, 4GB (up to 16GB Max. Capacity ) DDR3 installed | |
| Storage | One Drive Bay for SATA 2.5" HDD, 1*MSATA(SSD) space | |
| Watchdog Timer | Programmable 256 levels timer interval，setup by software | |
| Audio | Intel HD Graphics 4000 | |
| Ethernet | 4*10/100/1000 Mbps Ethernet Controller | |
| Graphics Engine | Intel® HD Graphics | |
| External I/O Interface |
Ethernet 4 (RJ-45) |
LAN1,10/100/1000Mbps intel 82583V,suports wake on LAN/PXE |
| LAN2,10/100/1000Mbps intel 82583V,suports wake on LAN/PXE | ||
| LAN3,10/100/1000Mbps intel 82574L,suports wake on LAN/PXE | ||
| LAN4,10/100/1000Mbps intel 82574L,suports wake on LAN/PXE | ||
| Audio | 1*LINE OUT & MIC-IN | |
| USB Port | 6*USB | |
| Display |
1*HDMI, Supports resolution up to 2560 x 1600@60Hz 1*VGA，Supports resolution up to 2048*1152@60Hz |
|
| Serial Port | 2*RS-232, 1*RS-232/485, 1*RS-232/422/485 | |
| Internal I/O Interface | USB | 3*USB2.0 pin header |
| PS/2 | 1*PS/2 KB/MS | |
| LVDS | 1*18/24-bit LVDS (Optional) | |
| LPT | 1*LPT (Optional) | |
| SIM | 1*SIM slot | |
| DIO | 1*16-bit DIO (Optional) | |
| General | Power Input Votage | DC_IN 12V~24V |
| Power Adapter | AC to DC, DC12V 90W (Optional) | |
| Expansion slot | 1*MINI PCIEx1 （with SIM slot) | |
| 1*MINI PCIEx1(supports MSATA by the code switch) | ||
| Dimensions (W x Dx H) | 246 x 209 x 84 mm | |
| Colour | Iron gray | |
| Mounting | Stand/ Wall | |
| Enclosure | Aluminum Housing | |
| Thermal Solution | Fanless | |
| Environment | Operating Temperature | -10 ~ 60°C |
| Storage Temperature | -40 ~ 80°C | |
| Relative Humidity | 5~ 95% (non-condensing) |
