BASIC INFO
| 12.1" inch Industrial Monitor | |
| Specifications | |
| PRODUCT MODE | FPM-6012 /FPM-6012-T |
| CASE MATERIAL/COLOUR | Aluminum alloy /Gray |
| TOUCH FUNCTION | Optional, Industrial five-wire resistive touch screen(USB interface) |
| PANEL TYPE | 12.1 inch 4:3 TFT-LCD screen |
| OPTIMAL RESOLUTION | 1024x768 |
| DISPLLAY AREA | 245.76 (H) x184.32 (V) mm |
| VIEWING ANGLE | (H)80/(V)80 |
| BRIGHTNESS | 350cd/㎡ |
| Backlight MTBF(hrs) | 30000 |
| SIGNAL INTERFACE | HDMI,VGA |
| AUDIO OUTPUT | 1 Ø3.5 PhoneJack audio output interface (only available for HDMI signal input) |
| CONTROL MODE | Panel button |
| POWER | DC12V |
| DEFAULT PLUG | Default Chinese standard.Free replacement:EU standard/US standard/UK standard according to order |
| Expansion interface | 3*USB2.0 |
| Dimensions (LxWxH) (mm) | 340*263*48mm(W*D*H) |
| Mounting | Panel embedded,VESA |
| Ordering Info. | |
| Item No. | Description |
| FPM-6012 | 12.1"inch Monitor with tempered glass, Without resistive touch,no Speaker |
| FPM-6012-T | 12.1"inch Monitor with resistive touch (USB interface),with built-in Speaker 2W amplifier SPK-Out |
