详细信息
CPU:板载 Intel Atom D525 GPU
芯片组：Intel 82801+ICH8-M
内存：板载2.0GB DDR3
I/O端口:4*LAN,1*VGA,1*LINE OUT&MIC,4*USB,1*HDMI
串口：2*RS-232,1*RS-232/485,3*RS-232/422/485
看门狗:256级,可编程时间到中断、时间到系统复位
存储:1*2.5"SATA盘位,1*CF槽位(可选购)
扩展槽:2个PCI(或2个PCIE x1或1个PCI、PCIEX1)槽位,1x mPCIE槽位
电源:DC_12~24V
尺寸:215*209 *135mm(W*D*H)
| Category | Attribute | Value |
| System Hardware | Processor | Intel Atom® Processor D525 (1M Cache, 1.80 Ghz) |
| BIOS | 8Mb AMI SPI | |
| Chipset | Intel 82801HBM(ICH8-M) | |
| Memory | 2GB (up to 4GB Max. Capacity ) DDR3 installed | |
| Storage | One Drive Bay for SATA 2.5" HDD, 1*CF (Optional) | |
| Watchdog Timer | Programmable 256 levels timer interval | |
| Audio | High Definition Audio (HD) | |
| Ethernet | 4*10/100/1000 Mbps Ethernet Controller | |
| Graphics Engine | Intel® HD Graphics | |
| External I/O Interface | LAN | 4 (RJ-45) |
| Audio | 1*LINE OUT & MIC-IN | |
| USB Port | 4*USB | |
| Display | 1*HDMI, 1*VGA, 1*SIM (Optional) | |
| Serial Port | 2*RS-232, 1*RS-232/485, 3*RS-232/422/485 | |
| Internal I/O Interface | VGA | 1*VGA (Optional) |
| PS/2 | 1*PS/2 KB/MS | |
| LVDS | 1*18/24-bit LVDS (Optional) | |
| LPT | 1*LPT (Optional) | |
| SIM | 1*SIM (Optional) | |
| DIO | 1*16-bit DIO (Optional) | |
| General | Power Input Votage | DC_IN 12V~24V |
| Power Adapter | AC to DC, DC12V 60W (Optional) | |
| Expansion slot | 2*PCI slot (2*PCIEx1 slot or 1*PCI slot/1*PCIEx1 optional) | |
| Dimensions (W x Dx H) | 215 x 209 x 135 mm | |
| Colour | Iron gray | |
| Mounting | Stand, Wall | |
| Enclosure | Aluminum Housing | |
| Thermal Solution | Fanless | |
| Environment | Operating Temperature | -10 ~ 60°C |
| Storage Temperature | -40 ~ 80°C | |
| Relative Humidity | 5~ 95% (non-condensing) |
